Halo H99TAT Recessed Housing, 8 in L x 5-1/4 in W x 5 in H Dimensions, New Construction, Steel

Halo

Halo H99TAT Recessed Housing, 8 in L x 5-1/4 in W x 5 in H Dimensions, New Construction, Steel

$18.99$18.99
Halo H99TAT Recessed Housing, 8 in L x 5-1/4 in W x 5 in H Dimensions, New Construction, Steel
  • Ceiling Opening Size: 4-3/8 in
  • Ceiling Type: Non-Insulated
  • Construction Type: New Construction
  • Dimensions: 8 in L x 5-1/4 in W x 5 in H
  • Includes: (3) Wiring Connectors Cut-Outs Locking Screw
  • Model #: H99TAT
  • UPC #: 080083584260
  • SKU: 9008483

Your shopping list will be used for pickup in-store

Product Details

The H99TAT is a small aperture Non-IC AIR-TITE™ housing for providing accent and task lighting. The H99TAT is designed for use in non-insulated ceiling or for insulated ceilings but insulation must be kept 3 in from all sides of the housing. Non-IC Housing is AIR-TITE™ but insulation must be kept 3 in away from all sides of housing.

Key Features

  • Die-formed housing and plaster frame
  • Housing may be removed from plaster frame for junction box access
  • Galvanized steel die-formed construction
  • The inner housing can be removed from plaster frame to provide access to the junction box
  • Positioned to accommodate straight conduit runs
  • Four 1/2 in trade size conduit knockouts with true pry-out slots
  • Slide-N-Side™ wire traps allow non-metallic sheathed cable to be installed without tools and without removing knockouts
  • Accepts a wide range of non-metallic (type NM) sheathed cables, the standard cable types used in lighting in both US and Canada
  • Pre-installed nail easily installs in regular lumber, engineered lumber and laminated beams
  • Safety and guidance system prevents snagging, ensures smooth straight nail penetration and allows bar hangers to be easily removed if necessary

Item Specifications

Ceiling Opening Size4-3/8 in
Ceiling TypeNon-Insulated
Construction TypeNew Construction
Dimensions8 in L x 5-1/4 in W x 5 in H
Includes(3) Wiring Connectors Cut-Outs Locking Screw
MaterialSteel
Mounting TypeRecessed
Recessed Can Diameter4 in
MORE DETAILS:
  • Application: For accent or task lighting
